Illume
Illume is a translucent light diffusing layer that is applied to the back of Lumicor panels. Illume helps to spread light evenly across the panel, eliminate hotspots, and conceal bulbs and fixtures for a clean aesthetic. This add-on is offered in three variations for compatibility with multiple lighting options and resin types. The Lumicor sales team will help you choose the best variation for your project.
Download Illume Info Sheet
Illume Variations
Illume | Recommended for: Lumilight Rigid
Illume Film | Recommended for: Lumilight Rigid
Illume LX | Recommended for: Lumilight Flex
Add-On Specifications
Resin Compatability
Illume | Lumiclear, Lumishield EX
Illume Film | Lumiclear, Lumiform, Lumishield EX
Illume LX | Lumiclear
Sizes
Illume may be added to these sheet sizes:
- 48″ x 96″ (1219 x 2438 mm)
- 48″ x 120″ (1219 x 3048 mm)
Gauges
Illume | Up to .040″ (1mm)
Illume Film | .003″ (.08 mm)
Illume LX | .118 (3mm)*
*Illume LX replaces the back .118″ (3mm) of resin and does not add thickness to a panel
Finishes (applied side)
Illume | Matte or Frost
Illume Film | Matte
Illume LX | Matte or Frost
Fabrication
Panels with Illume may be cut, formed, and finished. All standard forms of fabrication may be used (see fabrication guides under Resources).
Lumicor must provide all cutting services for Illume Film or warranty is void.
Light Transmission
Illume | 62%
Illume Film | 60%
Illume LX | 53%
Décors
Illume may be combined with any Lumicor décor.
